Periodic Pool Table
Author:
Senan Sekhon
Last Updated:
4 года назад
License:
Creative Commons CC BY 4.0
Аннотация:
A billiards-themed periodic table, made with TikZ
\begin
Discover why 18 million people worldwide trust Overleaf with their work.
\begin
Discover why 18 million people worldwide trust Overleaf with their work.
\documentclass{article}
\usepackage[a4paper,landscape,top=0in,bottom=0in,left=0in,right=0in]{geometry}
\usepackage[dvipsnames]{xcolor}
\usepackage{tikz,pgf}
%Colors for table cloth and cushions
\definecolor{tablecol}{HTML}{067345}
\definecolor{cushcol}{HTML}{00AD2B}
%Colors for each type of element
\definecolor{alk}{HTML}{960500}
\definecolor{alke}{HTML}{7A0064}
\definecolor{trans}{HTML}{A69D00}
\definecolor{lan}{HTML}{118274}
\definecolor{act}{HTML}{182CAD}
\definecolor{post}{HTML}{00C0D1}
\definecolor{semi}{HTML}{646464}
\definecolor{non}{HTML}{6100C9}
\definecolor{noble}{HTML}{050066}
%Created by Senan Sekhon
%Created March 6, 2021
%Conditional commands for different argument values. From https://tex.stackexchange.com/questions/179333/new-command-with-cases
\def\eqifcase #1#2#3{\eqifcaseA #1#2#1{#3}\end }
\def\eqifcaseA #1#2#3{\ifx #1#2\eqifcaseDo{#3}\fi \eqifcaseA #1}
\def\eqifcaseDo #1\fi #2\end{\fi #1}
\newcommand{\stripecode}[1]{\eqifcase{#1}{%Defines stripe pattern based on period
{1} %stripe pattern for period 1
{(-0.5,-0.5) rectangle (0.5,0.5)
(0,0) circle (0.25)}
{2} %stripe pattern for period 2
{(-0.5,-0.35) rectangle (0.5,0.35)
(0,0) circle (0.25)}
{3} %stripe pattern for period 3, stripe width 0.03
{(-0.5,-0.35) rectangle (0.5,0.35)
(-0.5,-0.32) rectangle (0.5,0.32)
(-0.5,-0.29) rectangle (0.5,0.29)
(0,0) circle (0.25)}
{4} %stripe pattern for period 4, stripe width 0.03
{(-0.5,-0.41) rectangle (0.5,0.41)
(-0.5,-0.38) rectangle (0.5,0.38)
(-0.5,-0.35) rectangle (0.5,0.35)
(-0.5,-0.32) rectangle (0.5,0.32)
(-0.5,-0.29) rectangle (0.5,0.29)
(0,0) circle (0.25)}
{5} %stripe pattern for period 5, stripe width 0.025
{(-0.5,-0.44) rectangle (0.5,0.44)
(-0.5,-0.415) rectangle (0.5,0.415)
(-0.5,-0.39) rectangle (0.5,0.39)
(-0.5,-0.365) rectangle (0.5,0.365)
(-0.5,-0.34) rectangle (0.5,0.34)
(-0.5,-0.315) rectangle (0.5,0.315)
(-0.5,-0.29) rectangle (0.5,0.29)
(0,0) circle (0.25)}
{6} %stripe pattern for period 6, stripe width 0.022
{(-0.5,-0.456) rectangle (0.5,0.456)
(-0.5,-0.434) rectangle (0.5,0.434)
(-0.5,-0.412) rectangle (0.5,0.412)
(-0.5,-0.39) rectangle (0.5,0.39)
(-0.5,-0.368) rectangle (0.5,0.368)
(-0.5,-0.346) rectangle (0.5,0.346)
(-0.5,-0.324) rectangle (0.5,0.324)
(-0.5,-0.302) rectangle (0.5,0.302)
(-0.5,-0.28) rectangle (0.5,0.28)
(0,0) circle (0.25)}
{7} %stripe pattern for period 7, stripe width 0.02
{(-0.5,-0.48) rectangle (0.5,0.48)
(-0.5,-0.46) rectangle (0.5,0.46)
(-0.5,-0.44) rectangle (0.5,0.44)
(-0.5,-0.42) rectangle (0.5,0.42)
(-0.5,-0.4) rectangle (0.5,0.4)
(-0.5,-0.38) rectangle (0.5,0.38)
(-0.5,-0.36) rectangle (0.5,0.36)
(-0.5,-0.34) rectangle (0.5,0.34)
(-0.5,-0.32) rectangle (0.5,0.32)
(-0.5,-0.3) rectangle (0.5,0.3)
(-0.5,-0.28) rectangle (0.5,0.28)
(0,0) circle (0.25)}
}{not found}}
\newcommand{\ball}[4][0,0]{%Ball template for element
\begin{scope}[shift={(#1)}]
\shade[ball color=white] (0,0) circle (0.5);
\begin{scope}[even odd rule]
\clip \stripecode{#2};
\shade[ball color=#4] (0,0) circle (0.5);
\end{scope}
\node[font=\sffamily\bfseries\selectfont] at (0,0) {#3};
\end{scope}}
\begin{document}
\thispagestyle{empty}
\hspace{0pt}
\vfill %For vertical centering on page
\centering
\begin{tikzpicture}[scale=1.15,every node/.style={transform shape},font=\sffamily\bfseries\selectfont]
\begin{scope} %Pool Table
\def\pd{11.4} %Distance between centers of adjacent pockets
\def\wd{1} %Vertical/horizontal distance from center of pocket to edge of frame
\def\pc{0.5} %Radius of pocket
\pgfmathsetmacro\pv{\pc/sqrt(2)}
\def\bt{0.3} %Width of cushion
\fill[tablecol,rounded corners=6mm] (-\pd-\wd,-\pd/2-\wd) rectangle (\pd+\wd,\pd/2+\wd); %table cloth
\begin{scope} %wooden frame and corner plates
\clip [rounded corners=6mm] (-\pd-\wd,-\pd/2-\wd) rectangle (\pd+\wd,\pd/2+\wd) %Outer boundary
[sharp corners] (-\pd,-\pd/2+2*\pv)--(-\pd-\pv,-\pd/2+\pv) arc(-225:-45:\pc)--(-\pd+2*\pv,-\pd/2)--(-2*\pv,-\pd/2)--(-\pv,-\pd/2-\pv) arc(-135:-45:\pc)--(2*\pv,-\pd/2)--(\pd-2*\pv,-\pd/2)--(\pd-\pv,-\pd/2-\pv) arc(-135:45:\pc)--(\pd,-\pd/2+2*\pv)--(\pd,\pd/2-2*\pv)--(\pd+\pv,\pd/2-\pv) arc(-45:135:\pc)--(\pd-2*\pv,\pd/2)--(2*\pv,\pd/2)--(\pv,\pd/2+\pv) arc(45:135:\pc)--(-2*\pv,\pd/2)--(-\pd+2*\pv,\pd/2)--(-\pd+\pv,\pd/2+\pv) arc(45:225:\pc)--(-\pd,\pd/2-2*\pv)--cycle; %Inner boundary
% Alternative inner boundary: (-\pd,-\pd/2+\pc) arc(-270:0:\pc)--(-\pc,-\pd/2) arc(-180:0:\pc)--(\pd-\pc,-\pd/2) arc(-180:90:\pc)--(\pd,\pd/2-\pc) arc(-90:180:\pc)--(\pc,\pd/2) arc(0:180:\pc)--(-\pd+\pc,\pd/2) arc(0:270:\pc)--cycle;
\fill[Brown] (-\pd-\wd,-\pd/2-\wd) rectangle (\pd+\wd,\pd/2+\wd); %wooden frame
\foreach \sa in {-1,1}
\foreach \sb in {-1,1}
\fill[gray!80] ({\sa*\pd},{\sb*\pd/2}) rectangle ({\sa*(\pd+\wd)},{\sb*(\pd/2+\wd)}); %corner plates
\end{scope}
\foreach \sh/\ro in {{(-\pd/2,-\pd/2)}/0,{(\pd/2,-\pd/2)}/0,{(\pd,0)}/90,{(\pd/2,\pd/2)}/180,{(-\pd/2,\pd/2)}/180,{(-\pd,0)}/270}
\fill[cushcol,shift=\sh,rotate=\ro] (-\pd/2+2*\pv,0)--(\pd/2-2*\pv,0) [rounded corners=2mm]--(\pd/2-2*\pv-\bt,\bt) --(-\pd/2+2*\pv+\bt,\bt) [sharp corners]--cycle; %cushions
\foreach \pocket in {(-\pd,-\pd/2),(0,-\pd/2),(\pd,-\pd/2),(-\pd,\pd/2),(0,\pd/2),(\pd,\pd/2)}
\fill[black] \pocket circle (0.5); %pockets
%Diamond finishing on frame
\foreach \q in {-3,-2,-1,1,2,3}
\foreach \r in {-1,1}
{\begin{scope}[shift={({\q*\pd/4},{\r*(\pd/2+\wd/2)})},xscale=0.16,yscale=0.28]
\clip (1,0) arc(-90:-180:1) arc(0:-90:1) arc(90:0:1) arc(180:90:1)--cycle;
\fill[gray!60] (0,0) circle (1); %finishes on long edge
\end{scope}}
\foreach \q in {-1,1}
\foreach \r in {-1,0,1}
{\begin{scope}[shift={({\q*(\pd+\wd/2)},{\r*\pd/4)})},xscale=0.28,yscale=0.16]
\clip (1,0) arc(-90:-180:1) arc(0:-90:1) arc(90:0:1) arc(180:90:1)--cycle;
\fill[gray!60] (0,0) circle (1); %finishes on short edge
\end{scope}}
\end{scope}
\begin{scope}[shift={(-8.5,-1.5)}] %Periodic Table
%Some elements have the prefix \small in front of their atomic symbols, as the symbols are too large to fit nicely into the white circles designated for them
\ball[0,6]{1}{H}{white} %Hydrogen
\ball[17,6]{1}{He}{noble} %Helium
\begin{scope}[shift={(0,0)}] %Alkali Metals and Alkaline-Earth Metals
\ball[0,5]{2}{Li}{alk} %Lithium
\ball[0,4]{3}{Na}{alk} %Sodium
\ball[0,3]{4}{K}{alk} %Potassium
\ball[0,2]{5}{Rb}{alk} %Rubidium
\ball[0,1]{6}{Cs}{alk} %Cesium
\ball[0,0]{7}{Fr}{alk} %Francium
\ball[1,5]{2}{Be}{alke} %Beryllium
\ball[1,4]{3}{\small Mg}{alke} %Magnesium
\ball[1,3]{4}{Ca}{alke} %Calcium
\ball[1,2]{5}{Sr}{alke} %Strontium
\ball[1,1]{6}{Ba}{alke} %Barium
\ball[1,0]{7}{Ra}{alke} %Radium
\end{scope}
\begin{scope}[shift={(2,0)}] %Transition Metals
\ball[0,3]{4}{Sc}{trans} %Scandium
\ball[1,3]{4}{Ti}{trans} %Titanium
\ball[2,3]{4}{V}{trans} %Vanadium
\ball[3,3]{4}{Cr}{trans} %Chromium
\ball[4,3]{4}{\small Mn}{trans} %Manganese
\ball[5,3]{4}{Fe}{trans} %Iron
\ball[6,3]{4}{Co}{trans} %Cobalt
\ball[7,3]{4}{Ni}{trans} %Nickel
\ball[8,3]{4}{Cu}{trans} %Copper
\ball[9,3]{4}{Zn}{trans} %Zinc
\ball[0,2]{5}{Y}{trans} %Yttrium
\ball[1,2]{5}{Zr}{trans} %Zirconium
\ball[2,2]{5}{Nb}{trans} %Niobium
\ball[3,2]{5}{\small Mo}{trans} %Molybdenum
\ball[4,2]{5}{Tc}{trans} %Technetium
\ball[5,2]{5}{Ru}{trans} %Ruthenium
\ball[6,2]{5}{Rh}{trans} %Rhodium
\ball[7,2]{5}{Pd}{trans} %Palladium
\ball[8,2]{5}{Ag}{trans} %Silver
\ball[9,2]{5}{Cd}{trans} %Cadmium
\ball[1,1]{6}{Hf}{trans} %Hafnium
\ball[2,1]{6}{Ta}{trans} %Tantalum
\ball[3,1]{6}{W}{trans} %Tungsten
\ball[4,1]{6}{Re}{trans} %Rhenium
\ball[5,1]{6}{Os}{trans} %Osmium
\ball[6,1]{6}{Ir}{trans} %Iridium
\ball[7,1]{6}{Pt}{trans} %Platinum
\ball[8,1]{6}{Au}{trans} %Gold
\ball[9,1]{6}{\small Hg}{trans} %Mercury
\ball[1,0]{7}{Rf}{trans} %Rutherfordium
\ball[2,0]{7}{Db}{trans} %Dubnium
\ball[3,0]{7}{Sg}{trans} %Seaborgium
\ball[4,0]{7}{Bh}{trans} %Bohrium
\ball[5,0]{7}{Hs}{trans} %Hassium
\ball[6,0]{7}{\small Mt}{trans} %Meitnerium
\ball[7,0]{7}{Ds}{trans} %Darmstadtium
\ball[8,0]{7}{\small Rg}{trans} %Roentgenium
\ball[9,0]{7}{Cn}{trans} %Copernicium
\end{scope}
\begin{scope}[shift={(2,-3)}] %Lanthanides and Actinides
\ball[0,1]{6}{La}{lan} %Lanthanum
\ball[1,1]{6}{Ce}{lan} %Cerium
\ball[2,1]{6}{Pr}{lan} %Praseodymium
\ball[3,1]{6}{\small Nd}{lan} %Neodymium
\ball[4,1]{6}{\small Pm}{lan} %Promethium
\ball[5,1]{6}{\small Sm}{lan} %Samarium
\ball[6,1]{6}{Eu}{lan} %Europium
\ball[7,1]{6}{Gd}{lan} %Gadolinium
\ball[8,1]{6}{Tb}{lan} %Terbium
\ball[9,1]{6}{Dy}{lan} %Dysprosium
\ball[10,1]{6}{Ho}{lan} %Holmium
\ball[11,1]{6}{Er}{lan} %Erbium
\ball[12,1]{6}{\small Tm}{lan} %Thulium
\ball[13,1]{6}{Yb}{lan} %Ytterbium
\ball[14,1]{6}{Lu}{lan} %Lutetium
\ball[0,0]{7}{Ac}{act} %Actinium
\ball[1,0]{7}{Th}{act} %Thorium
\ball[2,0]{7}{Pa}{act} %Protactinium
\ball[3,0]{7}{U}{act} %Uranium
\ball[4,0]{7}{\small Np}{act} %Neptunium
\ball[5,0]{7}{Pu}{act} %Plutonium
\ball[6,0]{7}{\small Am}{act} %Americium
\ball[7,0]{7}{\small Cm}{act} %Curium
\ball[8,0]{7}{Bk}{act} %Berkelium
\ball[9,0]{7}{Cf}{act} %Californium
\ball[10,0]{7}{Es}{act} %Einsteinium
\ball[11,0]{7}{\small Fm}{act} %Fermium
\ball[12,0]{7}{\small Md}{act} %Mendelevium
\ball[13,0]{7}{No}{act} %Nobelium
\ball[14,0]{7}{Lr}{act} %Lawrencium
\end{scope}
\begin{scope}[shift={(12,0)}] %Post-transition Metals, Metalloids, Non-metals and Noble Gases
\ball[0,5]{2}{B}{semi} %Boron
\ball[1,5]{2}{C}{non} %Carbon
\ball[2,5]{2}{N}{non} %Nitrogen
\ball[3,5]{2}{O}{non} %Oxygen
\ball[4,5]{2}{F}{non} %Fluorine
\ball[0,4]{3}{Al}{post} %Aluminum
\ball[1,4]{3}{Si}{semi} %Silicon
\ball[2,4]{3}{P}{non} %Phosphorus
\ball[3,4]{3}{S}{non} %Sulfur
\ball[4,4]{3}{Cl}{non} %Chlorine
\ball[0,3]{4}{Ga}{post} %Gallium
\ball[1,3]{4}{Ge}{semi} %Germanium
\ball[2,3]{4}{As}{semi} %Arsenic
\ball[3,3]{4}{Se}{non} %Selenium
\ball[4,3]{4}{Br}{non} %Bromine
\ball[0,2]{5}{In}{post} %Indium
\ball[1,2]{5}{Sn}{post} %Tin
\ball[2,2]{5}{Sb}{semi} %Antimony
\ball[3,2]{5}{Te}{semi} %Tellurium
\ball[4,2]{5}{I}{non} %Iodine
\ball[0,1]{6}{Tl}{post} %Thallium
\ball[1,1]{6}{Pb}{post} %Lead
\ball[2,1]{6}{Bi}{post} %Bismuth
\ball[3,1]{6}{Po}{post} %Polonium
\ball[4,1]{6}{At}{non} %Astatine
\ball[0,0]{7}{\small Nh}{post} %Nihonium
\ball[1,0]{7}{Fl}{post} %Flerovium
\ball[2,0]{7}{\small Mc}{post} %Moscovium
\ball[3,0]{7}{Lv}{post} %Livermorium
\ball[4,0]{7}{Ts}{non} %Tennessine
\ball[5,5]{2}{Ne}{noble} %Neon
\ball[5,4]{3}{Ar}{noble} %Argon
\ball[5,3]{4}{Kr}{noble} %Krypton
\ball[5,2]{5}{Xe}{noble} %Xenon
\ball[5,1]{6}{Rn}{noble} %Radon
\ball[5,0]{7}{\small Og}{noble} %Oganesson
\end{scope}
\end{scope}
\begin{scope}[scale=0.9,shift={(-11,-8.5)},every node/.style={shift={(\b,0)},right}] %Legend for Types of Elements
\def\a{0.8}
\def\b{0.4}
\shade[ball color=alk] (0,0) circle (0.3) node{Alkali Metals};
\shade[ball color=alke] (0,-\a) circle (0.3) node{Alkaline-Earth Metals};
\shade[ball color=trans] (0,-2*\a) circle (0.3) node{Transition Metals};
\shade[ball color=lan] (0,-3*\a) circle (0.3) node{Lanthanides};
\shade[ball color=act] (0,-4*\a) circle (0.3) node{Actinides};
\shade[ball color=post] (5,0) circle (0.3) node{Post-transition Metals};
\shade[ball color=semi] (5,-\a) circle (0.3) node{Metalloids};
\shade[ball color=non] (5,-2*\a) circle (0.3) node{Non-metals};
\shade[ball color=noble] (5,-3*\a) circle (0.3) node{Noble Gases};
\end{scope}
\begin{scope}[scale=0.9,shift={(6.8,-9.5)}] %Legend for Periods
\def\sp{1.2}
\ball[-3*\sp,0]{1}{1}{black}
\ball[-2*\sp,0]{2}{2}{black}
\ball[-\sp,0]{3}{3}{black}
\ball[0,0]{4}{4}{black}
\ball[\sp,0]{5}{5}{black}
\ball[2*\sp,0]{6}{6}{black}
\ball[3*\sp,0]{7}{7}{black}
\node at (0,1) {Stripes denote period (number of shells)};
\end{scope}
\begin{scope}[shift={(-7,4.7)}] %Pool cue Title Label
\def\cl{14} %Length of cue
\def\tr{0.2} %Half-width of tip of cue
\def\br{0.3} %Half-width of base of cue
\shade[bottom color=white,top color=black!40] (0,\tr)--(\cl,\br)--(\cl,-\br)--(0,-\tr)--cycle;
\shade[left color=Sepia!20,right color=Sepia] (\cl,\br) arc(15:-15:{(2+sqrt(3))*\br})--(\cl,-\br)--({2*\cl/3},{-(\tr+2*\br)/3})--({5*\cl/6},{-(\tr+5*\br)/12})--({2*\cl/3},0)--({5*\cl/6},{(\tr+5*\br)/12})--({2*\cl/3},{(\tr+2*\br)/3})--cycle;
\fill[gray!10] (0,\tr)--({\cl/12},{(11*\tr+\br)/12}) arc(15:-15:{(2+sqrt(3))*(11*\tr+\br)/12})--({\cl/12},{-(11*\tr+\br)/12})--(0,-\tr)--cycle;
\shade[ball color=Cerulean!50] (0,0) ellipse (2*\tr/5 and \tr);
\node[xshift=0mm] at (\cl/2,0) {PERIODIC POOL TABLE};
\end{scope}
\node[scale=1.5] at (6,-10) {Designed in {\normalfont\LaTeX} and {\normalfont Ti\textit{k}Z} by Senan Sekhon};
\end{tikzpicture}
\vfill %For vertical centering on page
\hspace{0pt}
\end{document}
